1MWBOX Overseas Mobile Mine

ROAD LEGAL, FULLY MOBILE SOLUTION FOR CRYPTO MINING

1MWBOX is for clients interested in more energy at more competitive rates. It's easily deployed to follow the best energy prices anywhere.

TOP KW CAPACITY ASIC MINERS ON THE MARKET INA 40 FT SIZE UNIT

1MWBOX resembles shipping containers on the outside, but it is designed inside and out for Bitcoin miners and maximum computer performance.

EFFICIENT OPERATIONS ENCLOSURE

1MWBOX is for clients interested in accessing more energy at more competitive rates. It can be easily deployed to track the best energy prices anywhere.

FITS FLEXIBLE SIZES AND TYPES OF CRYPTO HARDWARE FOR RAPID DEPLOYMENT

Bitcoin mining farm equipment will continue to evolve, and 1MWBOX offers the flexibility to help you stay competitive in your mining operations.

1MWBOX overseas mobile mine

NA20/40 Standard Edition

NA40 cETLus full container certified version
Basic data
The length, width, and height of the encrypted mining box (mm)

20HQ 6058*2438*2896mm
40HQ 12192*2438*2896mm

40HQ
12192*2438*2896mm

添加删除
Weight

NA20 3400kg / NA40 6500kg

6700kg
Classification Society

BUREAU VERITAS / CCS

BUREAU VERITAS / CCS
Equipment capacity

162 units at NA20 / 324 units at NA40

324 units
Rack

√

√
Outside temperature range, °F * * Check the miners' manufacturers specifications to avoid ASICs overheating due to high intake ambient temperature.

- 20 °F to + 100 °F

- 20 °F to + 100 °F

Electrical
Maximum Power

Maximum power NA20 600KW / NA40 1200KW

Maximum power 1200KW
Voltage Frequency

380-480v 50-60Hz

380-480v 50-60Hz
Electric Cabinet Configuration

Schneider 630A*2
Schneider 400A*3
ABB motor starter *8

Schneider 630A * 2
Schneider 63A * 28
ABB motor starter *8
PDU

12 hole positions c19 * 54 pieces (standard version is component certified PDU, which can be upgraded to P machine UL certified PDU)

12 holes c19 * 54（ UL certified）
Cable

√

√
Cooling System
suction fan

NA20 8 / NA40 16

16

添加删除
Separate control switch

√

√

添加删除
Single fan air flow rate CFM

22000CFM/unit

22000CFM/unit

添加删除
Air intake filtration system

√

√

添加删除
Cooling water curtain

√

√

添加删除
Safety Standard

添加删除
certification type

Electrical components comply with UL/CSA/ETL certification

Full container cETLus certification The certificate number can be found in the https://certs.intertek.com.cn/ Conduct a query and search for '1MWBOX'

添加删除

SHOW ALL SPECIFICATIONS

WHY CHOOSE OUR BITCOIN MINING FARMS

COMFORTABLE TERMS AND CONDITIONS

Unlike industry standards, we offer highly flexible payment terms. Manufacturing begins after an initial down payment, and you pay for the remainder based on the timely progress of the product.

MINING OPERATIONS WITH ADDITIONAL OPTIONS

When you purchase a mobile data center, you become a partner with 1MWBOX. We assist you in developing a complete cryptocurrency mining farm from the ground up, and we also offer the option to manage your crypto mining farm for a small monthly fee. With our 24/7 miner hosting and equipment management services, you can rest easy knowing our team is taking care of your mining operations.

YOU NO LONGER DEPEND ON THE COST OF ANY ONE ENERGY SOURCE

1MWBOX is a fully mobile data center. It's easy to transport, and each 1MWBOX is built to meet all ISO standards. Since it complies with all international public road transportation codes, you can transport your Bitcoin mining farm on a flatbed, just like a shipping container. This allows you to relocate it to any source of affordable electricity anywhere in the world.

YOUR INVESTMENT IS COST EFFECTIVE AND CARRIES LESS RISK

Investing in a warehouse-type crypto mining farm connected to the grid is not only twice as expensive but also significantly riskier compared to investing in a mobile mining unit. Otherwise, your local power provider may raise electricity rates or even ban crypto mining in your area, potentially rendering all your infrastructure investments useless.

RAPID DEPLOYMENT AND INSTALLATION

1MWBOX CONTAINER CONNECTION

1MWBOX complies with specific permits and permissions wherever it is shipped. A licensed electrician must connect the 1MWBOX to the transformer or generator using the provided cables.

1MWBOX OFF LOADING / INSTALLATION

Every 1MWBOX is equipped with four hook points to facilitate easy loading and unloading using a crane, similar to handling a shipping container. The 1MWBOX can be loaded and offloaded using any crane capable of lifting 5 tons (for the 1MWBOX 20ft) or 10 tons (for the 1MWBOX 40ft).

1MWBOX CONTAINER SITE PREPARATION

1MWBOX CONTAINER DELIVERY

1MWBOX mobile data center comes in two sizes: a 20ft container size unit and a 40ft container size unit.

QUALITY INSTALLATION WARRANTY

MATERIALS

1MWBOX is a durable, using high-quality reinforced steel plates.

ELECTRICAL COMPONENTS

1MWBOX Inside electrical infrastructure is protected by high quality circuit breakers. Internal equipment should have at least three layers of circuit breaker protection.

1MWBOX copper wiring is designed for continuous operation with minimum power losses. Eton, ABB & Schneider Electric are the top choices for electrical circuit breakers in a standard 1MWBOX.

IT INFRASTRUCTURE

We give our clients the option to pick their own internet infrastructure depending on their technical requirements.
Ethernet cables are connected to each rack for 1MWBOX installation process

INSTALLATION

1MWBOX provides a full setup and a start-up guide，and a technical support personnel will be dispatched to remotely assist in coordinating the installation of 1MWBOX.

WARRANTY

A limited manufacturer's warranty is provided for each electrical component of the unit, and we maintain a stock of spare parts to promptly facilitate replacements.
